Analoge Drake SAT Receiver von Anfang an:

Receiver aus dem Land des frühen Satellitenempfangs für Kabelfernsehstationen - den USA

Einige Geräte gab es auch in Europa in entsprechend modifizierter Ausführung.


 Modelljahr/e Marke/Type/Modell Kurzbeschreibung VK - Preis
Drake ESR324E ~1980? Drake ESR 324E Earth Station Receiver Mono, PAL G Modulator, 70 MHz ZF,  keine FB!
Drake ESR 800 XT Plus
DRAKE ESR1224 DRAKE ESR 1224 INTEGRATED EARTH STATION RECEIVER
  • DIGITAL ON
  • SCREEN GRAPHICS
  • VIDEOCIPHER ll
  • DESCRAMBLER EQUIPPED

For US Market!
Drake ESR1252 DRAKE ESR 1252 EARTH STATION RECEIVER For US Market!
Drake ESR1255



 DRAKE ESR 1255 EARTH STATION RECEIVER Multi-voltage transformer and voltage selection to allow operation on most common worldwide voltages, (115,127, 220 and 240V, 50/60 Hz)

Tuning range of 950-1750 MHz with dual LNB inputs

Complete operation on C and Ku bands - C band tunes in 1 or 20 MHz steps Ku band in 1 MHz steps

Low noise IF with threshold extension provides a static threshold of less than 7 dB C/N Selectable IF SAW filters of 30, 25 22 and 16 MHz maximize performance

Automatically restores receiver parameters after loss of AC power Three video outputs - composite and filtered outputs with video de-emphasis of 525/625 with an additional Flat output to facilitate the interface of a MAC decoder

RS232 interface provides remote control of front panel receiver functions

Dual audio channels with 50 µSec 75 µSec 125 µSec j17 and companded de-emphasis choices

Compatible with Wegener audio transmissions

Audio is synthesized from 5 to 9 MHz and offers selectable bandwidths (125 230 and 400 kHz)

DNR™ Selectable Dynamic noise reduction
Drake ESR1324

DRAKE ESR 1324 Earth Station Receiver


  • Video Cipher II Plus
  • Descrambler Equipped

For US Market!
Drake ESR250E Drake 250E Motorised Analogue Satellite Receiver
DRAKE ESR1624U DRAKE ESR 1624U EARTH STATION RECEIVER  "VIDEO CIPHER" RS MODULE, UHF REMOTE ANTENNA, PLUS TWO RF CONNECTOR CABLES. (push-on type)

REMOTE CONTROL DIMENSIONS OF THIS ITEM (IN APPROX INCHES) ARE: 17 " x 14" x 4 3/8"
For US Market!
Drake ESR2000XT

DRAKE ESR 2000XT


Drake ESR2000XTPlus DRAKE ESR 2000XT plus      2F Eingänge ,36 V Steuerung, magn.- mechan. Pol für Corotor,  , low Threshold

                    2 Fernbedienungen -1x IR-1x UHF über externe Antenne, AGC Ausgang nach außen geführt - mit Stecker zum Anschluß an einen Egis Rotor,
